Water treatment plant, 2,075 and 700 kVA
- Scope
- fuel day tanks of 1,000 and 2,500 l
- Result
- backup for a continuous process
Solution
Backup power for industry and infrastructure
100-3,000 kVA units with ATS, parallel operation and synchronization. For large sites - operation on an 11 kV bus; for critical loads - storage for uninterrupted transfer.
Key figures
6 × 3,000 kVA
at 11 kV with PLC synchronization, waste-to-energy plant
manufacturer data30-4,000 A
automatic transfer switches
manufacturer data110 %
load in factory testing of every unit
manufacturer dataWhat an industrial facility needs
Process continuity
Stopping a furnace, pumping station or refrigeration costs more than a genset.
High power
Several units in parallel, grid synchronization, medium voltage operation.
Generator hall
Ventilation, exhaust, noise and vibration isolation in an existing building.
Testing
Regular load starts and reports for the chief power engineer.
Solution
How it works
Gensets with ATS and synchronization, generator hall design or containerized design, storage for critical loads.
- DesignSingle-line diagram, load step calculation, ventilation, exhaust and noise.
- Supply and installationUnits in the generator hall or containers, fuel system, cable lines.
- TestingCommissioning, load testing with a load bank, staff training.
- OperationScheduled service, regular starts, remote monitoring.
- primary source
- backup
- unstable
- not available
Storage eliminates the power interruption during transfer to gensets.
Scope of supply
| Item | Scope |
|---|---|
| Generating sets | 100-3,000 kVA, open, enclosed or containerized |
| Controls | auto-start, synchronization and parallel operation controllers, PLC |
| Distribution | ATS 30-4,000 A, main switchboard, 11 kV operation via neutral grounding resistor |
| Fuel | fuel day tanks, double-wall tanks, automatic fuel transfer |
Parallel operation and synchronization are project-specific; controllers are selected for the site scheme.
See also: Lower capacity charges · Backup data center site
Projects using this solution
Manufacturer data. Details and references on request after approval by customers.
Waste-to-energy plant, 6 × 3,000 kVA
- Scope
- 11 kV operation, PLC synchronization
- Result
- parallel operation of six units
Public sector data center, 2,000 kVA
- Scope
- parallel operation with trigeneration and grid, 4,000 A main switchboard, 2,200 kW load bank
- Result
- full-load testing on site
Data center, 12+1 units of 2,750 kVA at 11 kV
- Scope
- neutral grounding resistor, redundant PLC synchronization, 4 underground tanks of 40,000 l, IP54 containers
- Result
- 75 dBA at 10 m; turnkey with 10-year service
Other solutions
Data center backup power
1-3 MVA units with data center rating, containerized power modules and fuel for 48-72 hours.
Learn moreGensets for base stations
48 V DC gensets and solar hybrids: 40-60 % fuel savings.
Learn moreMines, oil and gas fields, camps
Containerized units and hybrid with storage: less fuel, fewer deliveries and engine hours.
Learn morePower before grid connection
Containerized and trailer-mounted units while waiting for the grid, then site backup.
Learn moreGenset + storage hybrid
The genset runs less often and at efficient load: less fuel, fewer engine hours and site visits.
Learn moreRequest
Tell us about your site
Load and load profile, operating mode (backup or primary source), climate, grid availability, noise and fuel requirements. We will reply with a configuration, lead time and proposal.
